1. Adopt Danfoss refrigerated scroll compressor, adaptive scroll technology, low failure rate and high reliability.
2. Optimized design of the refrigeration circuit, brazed connection, easy to install, and higher air tightness.
3. Novel and efficient copper tube fin condenser, not easy to be dirty and blocked, high heat exchange rate and long service life.
4. No additional configuration is required, a truly ultra-wide application range (+15ºC~-18ºC)
5. Industrial and commercial type, variable speed fan, low vibration, low noise, and more stable operating pressure.
6. Beautiful appearance design and excellent weather resistance.
7. The products are certified by Danfoss, which makes the after-sales more worry-free.
Technical Parameters：
|
Model |
HP |
Compressor Model |
Voltage |
Condenser Fan |
Refrigerator |
Cooling Capacity W (evaporating temperature ℃) |
|
(V) |
Diameter*Quantity |
-25℃ |
||||
|
KLZ200 |
2 |
MLZ015 |
220/380 |
450*1 |
R404A |
1900 |
|
KLZ300 |
3 |
MLZ021 |
220/380 |
450*1 |
R404A |
2020 |
|
KLZ350 |
3.5 |
MLZ026 |
220/380 |
450*1 |
R404A |
2560 |
|
KLZ400 |
4 |
MLZ030 |
220/380 |
550*1 |
R404A |
2910 |
|
KLZ400S |
4 |
MLZ030 |
220/380 |
450*2 |
R404A |
2910 |
|
KLZ500 |
5 |
MLZ038 |
380 |
550*1 |
R404A |
3410 |
|
KLZ500S |
5 |
MLZ038 |
380 |
450*2 |
R404A |
3410 |
|
KLZ600S |
6 |
MLZ045 |
380 |
450*2 |
R404A |
4050 |
|
KLZ750S |
7.5 |
MLZ058 |
380 |
550*2 |
R404A |
4660 |
|
KLZ900S |
9 |
MLZ066 |
380 |
550*2 |
R404A |
6520 |
|
KLZ1000S |
10 |
MLZ076 |
380 |
550*2 |
R404A |
8710 |
Air cooler for condensing unit:
