PERFORMANCE FEATURE
- Air energy heat pump enclosed drying system, only drains water but not heat, no energy loss, 100% heat recovery;
- Use electric energy, no pollution, energy saving and environmental protection;
- Airtight dehumidification and drying, less damage to the material structure, can solve the problems of blasting and saccharification during baking;
- No sulfur after drying, the material has good quality and reducibility;
- Closed hot air circulation, strong wind convection, no ventilation dead angle in the drying room, good consistency;
- Accurate temperature and humidity can only be controlled in sections, programmable + LCD touch screen intelligent control, fully automatic operation;
- No need to flip the material during the drying process, saving labor.
Technical data:
Model
SDJ-20DAABA
SDJ-20XAABA
SDJ-40DAABA
SDJ-40XAABA
SDJ-80DABBA
SDJ-120DACBA
SDJ-160DADBA
Drying Temperature
15℃~75℃
Dehumidification Capacity kg/h (return air temperature 45℃, humidity:65%RH)
20
20
40
40
80
120
160
Rated power input Kw
5.3
5.3
11.8
11
21.6
31.9
43.2
Auxiliary electric heating power Kw
7.2
7.2
13.5
13.5
18
18
18
Air volume m3/h
6100
6100
11100
11100
27900
37200
55800
Air way
at the top
at the bottom
at the top
at the bottom
at the top
at the top
at the top
Power supply
380V / 3N / 50Hz
Refrigerant
R134a
Functions
Heat up, dihumidification, exhaust humidity
Boundary dimension(length*width*height)mm
910*950*1455
910*860*1505
1210*1060*1765
1210*1160*1715
1670*1210*1815
2100*1410*1965
2250*1510*1915
Unit weight
245
230
390
370
850
1250
1680
