Parameters
| Model | TL-GH-002HC410 | TL-GH-003HC410 | TL-GH-005HC410S | TL-GH-006HC410S | TL-GH-008HC410S | TL-GH-010HC410S | ||
| Heating Capacity Range | KW | 2-11 | 4-13 | 6-18 | 10-23 | 13-28 | 16-36 | |
|
Heating (W10/7℃,W30/35℃) |
Heating Capacity | KW | 10.6 | 12.5 | 17.6 | 22.7 | 27.8 | 35.3 |
| Power Input | KW | 1.85 | 2.13 | 2.89 | 3.77 | 4.69 | 5.85 | |
| COP | W/W | 5.72 | 5.86 | 6.08 | 6.02 | 5.93 | 6.03 | |
|
Heating (W10/7℃,W40/45℃) |
Heating Capacity | KW | 9.04 | 10.8 | 15.2 | 19.45 | 23.9 | 30.1 |
| Power Input | KW | 1.80 | 2.30 | 2.84 | 3.75 | 4.59 | 5.87 | |
| COP | W/W | 5.02 | 4.69 | 5.35 | 5.19 | 5.21 | 5.13 | |
|
Heating (B0/-3℃,W30/35℃) |
Heating Capacity | KW | 7.74 | 9.15 | 12.67 | 16.21 | 20.15 | 25.56 |
| Power Input | KW | 1.69 | 1.91 | 2.67 | 3.47 | 4.34 | 5.44 | |
| COP | W/W | 4.57 | 4.8 | 4.75 | 4.67 | 4.64 | 4.70 | |
|
Cooling (W30/35℃,W23/18℃) |
Cooling Capacity | KW | 10.5 | 12.4 | 16.8 | 21.5 | 26.65 | 33.52 |
| Power Input | KW | 1.82 | 2.34 | 2.83 | 3.72 | 4.65 | 5.94 | |
| EER | W/W | 5.76 | 5.54 | 5.93 | 5.78 | 5.73 | 5.64 | |
| Rated Water Flow | (User Side) | M3/h | 1.70 | 2.0 | 2.8 | 3.6 | 4.5 | 5.6 |
| Rated Water Flow | (Source Side) | M3/h | 3.0 | 3.6 | 4.82 | 6.2 | 7.6 | 9.6 |
| Rated Voltage | V | 230 | 230 | 230(400) | 230(400) | 400 | 400 | |
| Compressor(Panasonic) | 9RD160ZAA21 | 9RD220ZAA21-V5 | 9KD420ZBA21 | 9KD420ZBA21 | 9VD550XAA21 | 9VD650XAA21 | ||
| 4-way Valve(Saginomiya) | STF-H0218 | STF-H0218 | STF-H0408 | STF-H0408 | STF-0750G | STF-0750G | ||
| Electronic Expansion Valve(Saginomiya) | UKV14D204 | UKV18D213 | UKV25D205 | UKV25D205 | UKV32D210 | UKV32D210 | ||
